Double Glazing
Product code : Brand : T.S.
Double Glazing glass is formed by assembling two or more glass plates between the factory conditions to accommodate dry air or gases suitable for ambient pressure.
It provides all of the heat, solar, noise control, safety and security requirements producing solutions for the needs of every living space.
Double Glazing / Insulated Glass Unit
General Properties:
-
Constructed from two or more glass panes separated by an insulating air or argon-filled space.
-
Provides thermal insulation by preventing heat loss in winter and heat gain in summer.
-
Reduces energy consumption and lowers heating and cooling costs.
-
Blocks external noise and enhances acoustic comfort indoors.
-
Minimizes condensation and fogging on interior glass surfaces.
-
Can be combined with Low-E, reflective, laminated, or tempered glass types.
Applications:
-
Residential exterior windows
-
Commercial and office facades
-
Storefront glazing and display windows
-
Glass partitions and balcony systems
-
Energy-efficient green building projects
Technical Specifications:
-
Total thickness: 14 mm – 40 mm
-
U-value: 1.0 – 2.8 W/m²K
-
Sound insulation: 30 – 40 dB
-
Light transmittance: 70% – 80%
-
Gas filling: Air or Argon (optional)
-
Standards: EN 1279, ISO 9001, CE Certified
Glass Combination Table:
| Inner Glass (mm) | Spacer (mm) | Outer Glass (mm) | Total Thickness (mm) | Notes |
|---|---|---|---|---|
| 4 | 12 | 4 | 20 | Standard residential window use |
| 4 | 16 | 4 | 24 | Enhanced insulation performance |
| 6 | 12 | 6 | 24 | Larger spans, better sound control |
| 6 | 16 | 6 | 28 | Improved thermal insulation |
| 6 | 16 | 8 | 30 | Curtain wall and office facades |
| 4 | 10 | 6 | 20 | Asymmetrical build, sound-prioritized |
| 4 | 20 | 4 | 28 | Wider gap for lower U-value |
| 5 | 12 | 5 | 22 | Medium-scale general applications |
| 6 | 20 | 6 | 32 | Maximum insulation for custom projects |
Design Considerations:
-
Thickness and gap should be selected based on climate zone and building orientation.
-
Asymmetrical or laminated glass should be used for sound-sensitive areas.
-
Proper U-value and gas filling are key for condensation prevention.
-
Accurate cutting plans reduce waste and lower costs.
